AD groups not replicating from template to firewall
260
Created On 07/25/23 18:20 PM - Last Modified 10/31/25 18:14 PM
Symptom
- List of groups in SAMAccountName format configured on group-mapping include-list on Panorama Template and is pushed to the firewall
- The firewall successfully shows the group-mapping configuration with the include-list on the web-ui as configured on Panorama
- Running "show user group list" command from the CLI, we don't see all the groups listed in the include-list
Environment
- Palo Alto Networks Panorama or Firewall appliance running on PAN-OS 9.1 and higher
Cause
- Some groups were moved to a different folder on Active Directory
- The firewall could not retrieve the included group from the groups sent by the AD server
Resolution
- Go to Device > user-id > group mapping
- Open the group mapping you want to modify and go to "Group Include List"
- Search the group name in the search bar and compare it with the ones in the included group list
- If the groups are in a different location, correct the location on Panorama then commit and push the configuration to the firewall
