如何从 Panorama CLI 查看 Prisma Access 远程网络服务 IP 和网络详细信息

6449

Created On 11/09/22 10:42 AM - Last Modified 02/02/24 06:09 AM

Objective

管理员需要通过命令行界面（CLI）从 Panorama 获取远程网络服务 IP 和网络信息。
此信息已在 Web UI 中提供。有关说明，请参阅本文档。 Web UI 上的相同信息如下所示。

Environment

Prisma Access 由 Panorama 管理。
任何 PAN-OS 版本
远程网络

Procedure

登录到 Panorama 命令行界面。

对于单租户设置，请运行以下命令以查看所需信息。

admin@Panorama> debug plugins cloud_services prisma-access query body b64eyJzZXJ2aWNlVHlwZSI6ImZ3YWFzIn0= action getNetworkDetailData

pass
{"@status": "success", "@code": "19", "result": {"@total-count": 4, "@count": 4, "entry": [{"name": "RN4", "Service IP Address": "x.x.x.156", "Local IP Address": "Citrix-IPSec-Tunnel-Default", "Static Subnet": ["192.168.4.0/24"], "EBGP Router": ["10.127.240.8"], "Branch AS and Router": [], "EBGP Router ECMP": null, "Branch AS and Router ECMP": null, "Inbound Access Apps": null, "Loopback IP Address": "10.127.240.8"}, {"name": "RN3", "Service IP Address": "x.x.x.156", "Local IP Address": "CloudGenix-IPSec-Tunnel-Default", "Static Subnet": ["192.168.3.0/24"], "EBGP Router": ["10.127.240.8"], "Branch AS and Router": [], "EBGP Router ECMP": null, "Branch AS and Router ECMP": null, "Inbound Access Apps": null, "Loopback IP Address": "10.127.240.8"}, {"name": "TestNetwork", "Service IP Address": "x.x.x.31", "Local IP Address": "CiscoASA-IPSec-Tunnel-Default", "Static Subnet": ["192.168.1.0/24"], "EBGP Router": ["10.127.240.4"], "Branch AS and Router": [], "EBGP Router ECMP": null, "Branch AS and Router ECMP": null, "Inbound Access Apps": null, "Loopback IP Address": "10.127.240.4"}, {"name": "RN2", "Service IP Address": "x.x.x.31", "Local IP Address": "CiscoISR-IPSec-Tunnel-Default", "Static Subnet": ["192.168.2.0/24"], "EBGP Router": ["10.127.240.4"], "Branch AS and Router": [], "EBGP Router ECMP": null, "Branch AS and Router ECMP": null, "Inbound Access Apps": null, "Loopback IP Address": "10.127.240.4"}], "redundancy-alert": []}}

对于多租户设置，请运行以下命令以查看所需信息。请参阅“其他信息”部分，查找每个租户的正文信息。

admin@Panorama> debug plugins cloud_services prisma-access query body b64eyJzZXJ2aWNlVHlwZSI6ImZ3YWFzIiwidGVuYW50TmFtZSI6IkxhYlRlbmFudG5heWEifQ== action getNetworkDetailData

pass
{"@status": "success", "@code": "19", "result": {"@total-count": 1, "@count": 1, "entry": [{"name": "Tenant1RN1", "Service IP Address": "x.x.x.67", "Local IP Address": "test25NEWTEST-RN", "Static Subnet": ["1.1.1.1/32"], "EBGP Router": ["172.16.9.8"], "Branch AS and Router": [], "EBGP Router ECMP": null, "Branch AS and Router ECMP": null, "Inbound Access Apps": null, "Loopback IP Address": "172.16.9.8"}], "redundancy-alert": []}}

Additional Information

响应为 json 格式。使用任何 json 解析器以人性化的方式对信息进行排序。
输出将列出 Web UI 中显示的相同信息。
相同的命令应该适用于所有全景图。
对于多租户，每个租户查询正文都不同。使用 https://panorama-IP/php/utils/debug.php 然后从 GUI 查询网络详细信息
在调试输出中搜索“正文”，并复制特定于租户的正文信息。下面的示例。此示例适用于另一个租户，因此正文与上面提到的正文不同。

Php 调试日志也可以从 /var/log/php.debug.log 下的 CLI 中捕获

<operations xml="yes">
    <request>
      <plugins>
        <cloud_services>
          <gpcs>
            <query>
              <action>getNetworkDetailData</action>
              <body>b64eyJzZXJ2aWNlVHlwZSI6ImZ3YWFzIiwidGVuYW50TmFtZSI6IkV4cGxpY2l0UHJveHkifQ==</body>
            </query>
          </gpcs>
        </cloud_services>
      </plugins>
    </request>
  </operations>
</request>
