Slowness observed when doing file transfer via GlobalProtect IPSec tunnel on PA-5200 Series Firewall

• Slowness is seen during file transfer( any protocol) via the ipsec/GP (ipsec).
• Firewall is not dropping any packet nor the latency being introduced.
• While checking the pcap from the client to the firewall transmit stage, you will notice the firewall is in inducing out of order packets.
• if you notice the ip.id 1672 and below ( identification id ) the pattern shows that its not the the network introducing out of order. Its the firewall while transmitting the packet is introducing the out of order.
• NOTE: Since we have to capture the packet while its being transmitted, you need to bounce the tunnel to get the keys to decrypt the ESP packets.

CLIENT pcap:

Firewall transmit stage pcap:

• Palo Alto Networks 5200 Series Firewalls
• PANOS above 10.0.x
• GlobalProtect (GP)

Software Issue.

1. The issue is resolved under PAN-273141.
2. Upgrade to one of the following PAN-OS will resolve the issue.

• • 12.2.0
  • 11.1.11
  • 10.2.17
  • 11.1.9
  • 11.1.6-h4
  • 11.1.4-h14
  • 11.1.7-h2
  • 10.2.13-h7
