DotW: Matrix/Capability of the Differing Interface Deployment Modes
Resolution
In this Discussion of the Week, we're accomodating a request from one of our community members, MicGioia!
There's a section in the Admin guide that shortly describes all types of interfaces and several ways they can be deployed:
Several other articles cover how to configure, deploy or benefit from a certain type of interface, but a simple matrix may come in handy to compare each interface's pros and cons, so here goes:
The Layer2 interface can be augmented with Layer 3 functionality (such as DHCP, NAT, and routing) ,so although it is not strictly Layer 2, the functionality is available on the interface.
| Supports: | Vwire | Layer 2 | Layer 3 | Tap |
| VLAN tags | y | y | y | y |
| Tagged subinterfaces | y | y | y | n |
| Untagged subinterfaces | n | n | y | n |
| Minimum physical interfaces | 2/vwire | 1 | 1 | 1/tap |
| Maximum physical interfaces | 2/vwire | all | all | all |
| Routing | n | y | y | n |
| NAT | y | y | y | n |
| Wirespeed/SPPP | y | y | y | y |
| QOS | y | y | y | n |
| DHCP | n | y | y | n |
| SSL decryption | y | y | y | y-inbound n-outbound |
| Captive Portal | y | y | y | n |
| Policy based forwarding | n | y | y | n |
Feel free to leave a comment if you think there are other capabilities you'd like to see added to this list.
The original discussion can be followed here.
Thanks for the good tip, MicGioia!
